Industrial Water Heater Water Manufacturer, Water Heater Components

ModelLightArea(m2)Vacuum TubeCapacity(Liters)20GP/40HQLoading QtyØ(mm)L(mm)NO.IPJG 100 GS1.45818001010071/172IPJG 150 GS2.15818001515052/125IPJG 200 GS2.85818002020039/96IPJG 250 GS3.55818002525033/80IPJG 300 GS4.25818003030028/68IPJG 400 GS5.65818004040021/52 IPJG 80 GS1.1258180088080/194IPJG 120 GS1.685818001212062

Featured Products




Vacuum Tube




Loading Qty

IPJG 100 GS1.45818001010071/172
IPJG 150 GS2.15818001515052/125
IPJG 200 GS2.85818002020039/96
IPJG 250 GS3.55818002525033/80
IPJG 300 GS4.25818003030028/68
IPJG 400 GS5.65818004040021/52
IPJG 80 GS1.1258180088080/194
IPJG 120 GS1.685818001212062/150
IPJG 160 GS2.245818001616048/116
IPJG 180 GS2.525818001818043/105
IPJG 240 GS3.365818002424034/82
IPJG 360 GS5.045818003636023/57

Technical Specifications :

  1. Inner Tank : SUS304-2B food-grade stainless steel - 0.4mm thickness , laser welding technology .

  2. Vacuum Tube : High efficient ALN/ALN-SS/CU coating , 58 x 1800mm vacuum tube - 1.6mm thickness , resist 25mm hail .

  3. Outer Tank : Painted galvanized steel - 0.4mm thickness , free-welding technology .

  4. Insulation Layer : High density polyurethane - 50mm thickness , 72 hours efficient thermal insulation .

  5. Frame support : Painted galvanized steel - 1.5mm thickness , anti-corrosive and anti-ultraviolet .

  6. M8 Stainless steel SUS 304 bolts and nuts .

  7. 58mm Silicone seal ring and dust ring

  8. Stainless steel SUS304 - 2.0mm thickness 3/4' or 1/2' inlet, outlet, air vent


Optional accessories :

  1. Aluminum component reflectors

  2. Electrical heater

  3. Magnesium anode rod

  4. Assistant tank - Cold water filling tank

  5. Solar Controller

Company information:
Changzhou Imposol New Energy Co., Ltd.Is located in Changzhou City of Jiangsu Province.Changzhou, a prefecture-level city in Jiangsu province, is located on the southern bank of the Yangtze River near the river mouth.Our company is a professional solar energy company in China which integrates research, manufacture and marketing.In recent years, our products have been well accepted by the European market, Australia, Africa and the Asian market because of high performance and reasonable price.We pay much attention to products' quality and company's credit.
As an OEM factory in China, it specializes in manufacturing solar water heaters and vacuum tubes.We have a workshop covering an area of 6000 square meters with a production capability of 100 thousand pieces of solar water heaters and 1 million pieces of vacuum tubes every year.These products have enjoyed a great popularity among many countries for many years because of their high performance and reasonable price.We have also designed some wonderful solar water projects which use solar collectors with metal vacuum tubes for hospitals, schools, factories and families.Customers either at home or abroad highly praise our projects for their high efficiency and excellent energy-saving system.
As the shortage of energy and pressure of environment pollution appear, the importance of the solar energy is increasing day by day.Thus in order to benefit people, Impose Solar will do its utmost to provide various solar products with high quality and efficiency.
